Product Features:
Beautiful and smooth appearance design;
Automatic temperature compensation patented technology, super anti-false alarm ability;
Anti-white light patented technology, the intensity is up to 2000 Lux;
LED ON/OFF optional;
Alarm output NC/NO is optional, adapt to different alarm hosts;
Adopt SMT technology, super anti-electromagnetic interference, radio frequency interference ability;
Technical parameter:
Working voltage: DC9-16V
Working current: ≤22mA (DC 12V)
Detection distance: 6m/10m optional
Detection angle: 15°
Sensor type: dual-element low-noise pyroelectric infrared sensor
Installation method: wall-mounted
Installation height: the best is 2.2m
Working temperature: -10℃~﹢50℃ (14℉~122℉)
Alarm output: normally closed/normally open optional contact capacity 60VDC, 300mA
Anti-dismantling switch: normally closed without voltage output, contact capacity 28VDC, 100mA
Dimensions: 90mm*50mm*33mm
